PROJECT MATURITY
POWER SCHEDULE TITLE
GLOBAL SETTINGS
POWER FACTOR
AMBIENT HEAT GAIN
UPS PLANNING SETTINGS
▼
DEMAND FACTOR
GROWTH FACTOR
MAX LOAD % TARGET
Set capacity, connections, and runtime in Edit device.
UPS TYPE
RUNTIME TARGET (MIN)
ADD FROM LIBRARY
Editable planning values. Verify selected equipment.
Dual PSU: Size each A/B feed for the full device load. Count device watts and heat once.
Library tools
CSV changes apply to new devices only.
CSV key
TBD: unknown · N/A: not applicable · Auto: suggested outlet.
All Input To Room: all watts become local heat.
Legacy Category Factor: retained from older files.
SPECIFIED PRODUCTS & REFERENCES
Manufacturer references. Enter project-specific loads.
Enter complete equipment input, including downstream loads. Count each host or supply once.
ADD CUSTOM DEVICE
VOLTAGE
PLACEMENT
TOTAL WATTS
0 W
0 VA
HEAT LOAD
0 BTU/hr
0.00 tons
ICT GEN. ALLOWANCE
0.0 kW
1.25× planning allowance
UPS LOADN/A
Rack settings and circuit notes
RACK SETTINGS
RACK LABEL
RACK SIZE (U)
PDU INPUT VOLTAGE
REDUNDANCY
RACK NOTES
LEVEL / FLOOR
OUTLET TYPE
CIRCUIT # / PANEL
Edit values here. Backup and connections: Edit device.
RACK DEVICEQTYW/UNITVTOTAL WAMPSRACK U
No devices in this rack yet.
🔧 WALL / FIELD AC INPUTS
DEVICEQTYW/UNITVTOTAL WAMPSBREAKER
No wall/field AC inputs yet. Include DC device demand at its power supply input.
PLEX Project Summary
PROJECT INFORMATION
ELECTRICAL LOAD SUMMARY
ICT GENERATOR ALLOWANCE
MECHANICAL / COOLING LOAD
Room heat plus allowances. Mechanical to verify final capacity and duty/standby operation.
WALL / FIELD DEVICES
Independent circuits: outside rack PDU
UPS SIZING & RUNTIME
CIRCUITS & BREAKER SIZING
Includes a 125% planning allowance. Electrical to confirm circuits and breakers.
PER-RACK BREAKDOWN
POWER CONSUMPTION & CIRCUIT SCHEDULE
- Power Factor. Default 0.90 applied to all loads. Adjust under Global Settings for known equipment behavior.
- 125% Planning Allowance. Applied once to preliminary circuit current and ICT generator load. This does not establish a code requirement or final equipment selection.
- Wall-Mount Device Wattages. Wall rows represent complete AC supply or system inputs. Include downstream controllers, readers, locks, losses, and charging once at the supply. Do not create independent AC rows for DC components. Verify the installed configuration.
- Cooling Load. Room heat watts, adjusted by the recorded load factor, × 3.41214 = BTU/hr. Blank room heat assumes all input stays in this room. Cooling allowance includes a 25% buffer and the configured ambient percentage.
- Generator Sizing. Total load × 1.25 (continuous). Growth recommendations show +25% and +50% above continuous.
- UPS Runtime. Individual connections and recorded manufacturer load points determine the result. No batteries are pooled, and no runtime is interpolated. Missing load points remain unknown. A/B checks each source at full transferred load; parallel systems require vendor modeling.
- Breaker Selection. Breaker shown is the next standard commercial size at or above calculated continuous-load current. Final breaker and conductor sizing by licensed electrical engineer.
- Redundant Power Supplies. Enter complete device input once. Confirm efficiency, loading, and failure behavior. A redundancy objective does not establish availability or N+1 compliance.
- Scope. Preliminary planning and coordination only. PLEX does not replace stamped electrical design. All outputs require review and sign-off by a licensed electrical engineer.
PLEX v2.75: Compiled by Limited Energy · limitedenergy.net · Open reuse permitted with credit.
